Sesame Grinding Mill With 5 Stone
Product Code: MN-HTT 1A
Used to grind the sesame seeds to produce tahini.
• Standard mill has 5 stones and has a capacity of 500 kg/hr. Mill with a capacity from 200 kg/hr to 500 kg/hr can be made.
• Standard mill has two primary stone rotating around the horizontal axis and two finishing stones rotating around the vertical axis.
• All stones are of same diameters; each 18 cm diameter. Upon request, bigger diameter stones can be mounted.
• Speed of all stones are same; 2800 RPM
• Stones are driven by three motors, each 7.5 KW
• Mounted tahini pump, 1.1 KW
• Closed cycle water cooling unit with water pump (0.55 KW) and fan (0.37 KW) to cool the the stones.
• By-pass line around the finishing stones, used when necessary.
• 304 stainless steel.
